Rt-Mspd2-30 Modular Proportional Amplifier
Rt-Mspd2-30 Modular Proportional Amplifier Valves Product Category Shipped Via FedEx or DHL
Products Description
The RT-MSPD2-30 is a next-generation industrial proportional amplifier engineered for precision signal conditioning in high-dynamic industrial environments. Built with advanced analog-digital hybrid circuitry, it delivers industry-leading accuracy, low-noise performance, and flexible configurability, making it the optimal choice for demanding applications requiring tight control over voltage/current signal scaling.
Technical Highlights
Programmable Gain Precision: 1-30x gain adjustment with 0.05x step resolution (vs. 0.1x in prior models), enabling ultra-fine tuning for sensitive systems.
Ultra-Low Noise Floor: ≤10μVrms (1-20kHz bandwidth), minimizing signal interference in high-precision measurement setups.
Dual-Mode Input/Output: Supports both analog (voltage/current) and digital (PWM) input formats, with selectable output ranges (0-5V, 0-10V, 4-20mA, 0-20mA).
Industrial Hardening: Enhanced EMI/RFI filtering (100kHz-1GHz attenuation ≥60dB) and thermal management for operation in -25°C to +85°C.
Key Specifications
| Category | Parameter | Specification |
| Electrical Characteristics | ||
| Model | RT-MSPD2-30 | Single-channel (fixed configuration) |
| Input Signal Types | Voltage/Current/PWM | Voltage: ±5V, ±10V (switch-selectable); |
| Current: 0-20mA, 4-20mA (switch-selectable); | ||
| PWM: 5-20kHz (duty cycle 0-100%) | ||
| Output Signal Types | Voltage/Current | Voltage: 0-5V, 0-10V (programmable); |
| Current: 4-20mA, 0-20mA (programmable) | ||
| Gain Range | - | 1.0x to 30.0x (0.05x step, digital potentiometer control) |
| Bandwidth (-3dB) | - | DC to 12kHz (typical; -0.5dB at 10kHz) |
| Non-Linearity Error | - | ≤0.02% F.S. (Full Scale, 25°C) |
| Input Impedance | Voltage Input | ≥15MΩ (differential, 1kHz) |
| Output Impedance | Voltage Output | ≤25Ω (low-impedance, 1kHz) |
| Signal-to-Noise Ratio (SNR) | - | ≥90dB (A-weighted, 20Hz-20kHz) |
| Power Requirements | ||
| Supply Voltage | - | ±12VDC to ±18VDC (nominal ±15VDC; ±5% tolerance) |
| Power Dissipation | - | ≤12W (max gain, ±18VDC) |
| Environmental | ||
| Operating Temperature | - | -25°C to +85°C (with derating above +70°C) |
| Storage Temperature | - | -40°C to +105°C |
| Humidity (Non-Condensing) | - | 10% to 90% RH |
| Mechanical | ||
| Dimensions (L×W×H) | - | 100mm × 75mm × 25mm (with heatsink) |
| Weight | - | 300g (net) |
| Protection Features | ||
| Overvoltage Protection (OVP) | - | ±22VDC (clamped, recoverable) |
| Short-Circuit Protection (SCP) | - | Auto-reset (current limit: 250mA) |
| EMI Filtering | - | 100kHz-1GHz attenuation ≥60dB |
Overvoltage Protection (OVP) - ±22VDC (clamped, recoverable)
Short-Circuit Protection (SCP) - Auto-reset (current limit: 250mA)
EMI Filtering - 100kHz-1GHz attenuation ≥60dB
