PVB5 PVB6 PVB10 PVB15 PVB20 PVB29 PVB45 Hydraulic Piston Pump For Industrial Hydraulic System
PVB5 PVB6 PVB10 PVB15 PVB20 PVB29 PVB45 Hydraulic Piston Pump for Industrial Hydraulic System
Send Inquiry
Product Introduction
Detailed pictures
 |  |
Model Description
| Model | Displacement in³/rev | Displacement cm³/rev | Flow @ 1800 rpm GPM | Flow @ 1800 rpm L/min | Max Pressure psi | Max Pressure bar | Max Speed rpm | Approx. Weight lbs | Approx. Weight kg |
|---|---|---|---|---|---|---|---|---|---|
| PVB5 | 0.643 | 10.5 | 5 | 18.9 | 3000 | 210 | 3600 | 16 | 7.3 |
| PVB6 | 0.843 | 13.8 | 6.5 | 24.6 | 2000 | 140 | 3200 | 16 | 7.3 |
| PVB10 | 1.29 | 21.1 | 10 | 37.9 | 3000 | 210 | 3200 | 30 | 13.6 |
| PVB15 | 2.01 | 32.9 | 15 | 56.8 | 2000 | 140 | 3000 | 30 | 13.6 |
| PVB20 | 2.61 | 42.8 | 20 | 75.7 | 3000 | 210 | 2400 | 57 | 25.9 |
| PVB29 | 3.76 | 61.6 | 29 | 109.8 | 2000 | 140 | 2400 | 57 | 25.9 |
| PVB45 | 5.76 | 94.4 | 45 | 170.3 | 3000 | 210 | 2200 | 210 | 95.3 |
Company profile
Exhibitions
